Процесор

1. Built in with an Intel® Quad-Core Celeron® N4120 (2.6 GHz)
   * Do not disassemble the onboard SoC and the heatsinks by yourself to avoid damage to these components.
2. 4 MB Cache

Підсистема
пам'яті

1. 2 x DDR4 SO-DIMM sockets supporting up to 16 GB of system memory
2. Dual channel memory architecture
3. Support for DDR4 2400/2133 MHz memory modules
4. Support for non-ECC memory modules

Графічний інтерфейс

1. 1 x D-Sub port, supporting a maximum resolution of 1920x1200@60 Hz
2. 1 x HDMI port, supporting a maximum resolution of 4096x2160@60 Hz
   * Support for HDMI 2.0 version and HDCP 2.2.

Аудіопідсистема

1. Realtek® Audio CODEC
2. High Definition Audio
3. 2/4/5.1/7.1-channel
   * You can change the functionality of an audio jack using the audio software. To configure 7.1-channel audio, access the audio software for audio settings.

Мережевий
LAN-інтерфейс

1. Realtek® GbE LAN chip (1 Gbps/100 Mbps)

Роз'єми для плат розширення

1. 1 x PCI Express x1 slot, running at x1
   (The PCIEX1 slot conforms to PCI Express 2.0 standard.)
2. 1 x M.2 Socket 1 connector for the wireless communication module

Інтерфейси накопичувачів

1. 1 x M.2 connector (Socket 3, M key, type 2280/2260/2242 SATA and PCIe 2.0 x2 SSD support)
2. 2 x SATA 6Gb/s connectors
   * Refer to "2-6 Internal Connectors," for the installation notices for the M.2 and SATA connectors.

Інтерфейс USB

1. 4 x USB 3.2 Gen 1 ports (2 ports on the back panel, 2 ports available through the internal USB header)
2. 4 x USB 2.0/1.1 ports (2 ports on the back panel, 2 ports available through the internal USB header)

Роз'єми на системній платі

1. 1 x 24-pin ATX main power connector
2. 1 x 4-pin ATX 12V power connector
3. 2 x SATA 6Gb/s connectors
4. 1 x SoC fan header
5. 1 x system fan header
6. 1 x M.2 Socket 3 connector
7. 1 x front panel header
8. 1 x front panel audio header
9. 1 x USB 3.2 Gen 1 header
10. 1 x USB 2.0/1.1 header
11. 1 x parallel port header
12. 1 x serial port header
13. 1 x Trusted Platform Module (TPM) header (2x6 pin, for the GC-TPM2.0_S module only)
14. 1 x Clear CMOS jumper

Роз'єми на задній панелі

1. 1 x PS/2 keyboard port
2. 1 x PS/2 mouse port
3. 1 x serial port
4. 1 x D-Sub port
5. 1 x HDMI port
6. 2 x USB 3.2 Gen 1 ports
7. 2 x USB 2.0/1.1 ports
8. 1 x RJ-45 port
9. 3 x audio jacks

Мікросхема
I/O-контролера

1. iTE® I/O Controller Chip

Контроль за станом системи

1. Voltage detection
2. Temperature detection
3. Fan speed detection
4. Fan speed control
   * Whether the fan speed control function is supported will depend on the cooler you install.

BIOS

1. 1 x 128 Mbit flash
2. Use of licensed AMI UEFI BIOS
3. PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0

Фірмові функції та технології

1. Support for Xpress Install
2. Support for @BIOS
3. Support for APP Center
   * Available applications in APP Center may vary by motherboard model. Supported functions of each application may also vary depending on motherboard specifications.

Bundled Software

1. Norton® Internet Security (OEM version)
2. LAN bandwidth management software

Операційна система

1. Support for Windows 11 64-bit
2. Support for Windows 10 64-bit
